ISUZU FVR 15 ton dump tip truck for sale

Customized ISUZU Dumper Truck suited for Mining Area working. Special Design ISUZU Dump Trucks.

features of ISUZU Dump Truck:

1. ISUZU FVR Dump Truck.

2. ISUZU 240HP 6HK1-TCNG40 6Cylinder

3. ISUZU MLD Forwards;

4. 10.00R20 Radial Tire.

5. with air Conodition. power steering, radio. ABS

6. Cargo size: 4800*2300*600mm

Specification

Specification of ISUZU FVR 240HP Dump Truck:

ISUZU Dump Truck
Chassis Model /Manufacturer
FVR QL1160
cab
With one sleeper
Overall Dimension
7300*2500*2860mm
Cargo size
4800*2330*550mm
Total Mass
33025Kg
Rated Payload
15000Kg
Kerb Weight
6800Kg
front overhang/rear overhang
1335/1700
Engine
Model/Rated Power
6HK1-TCNG40   178KW/240HP
6 cylinder
Displacement
7790CC
Emission Standard
Euro 4
manufacturer
QingLing ISUZU Motors
Type & Size of Tyre
10.00R20
driving type
4×2
Wheel Base
3900mm
Max Speed
90 Km/h
Cargo size
4800*2300*550mm
ISUZU MLD 6 forwards + 1 reverse, with air condition, power steering, Electrical glass, USB
Chassis Steel: Q345R (16MnR)
Cabin Steel: Cold-Rolled Carbon Steel Q235
Frame Breadth : 258*85*10+4mm
Double Triple – deck sheet: 10+4mm
System Brake: air Brake
Front Axle( Loading capacity): 6.3T
Rear Axle( Loading Capacity): 13T
Battery: 12V*2  115Ah*2
